Features

- Please test to add current limiting resistor, it will be very easy to burn out the LED resistance of a few hundred to 1000ohm.
- R: wavelength 630-640nm Brightness 1000-1200mcd Voltage 1.8-2.0V
- G: wavelength 515-512nm Brightness 3000-5000mcd Voltage 3.2-3.4V
- B: wavelength 465-475nm Brightness 2000-3000mcd Voltage 3.2-3.4V

Specifications

- Size: 5mm
- Emitted Colour : Red / Green / Blue
- Pins sequence: RED/Common Cathode/Green/Blue
- Luminous Intensity: 4000/8000/5000mcd
- Voltage (V) : 3.2~3.4
- Quantity: 50pcs
